Product Advantages
◆Excellent extreme pressure performance: The extremely high thermal stability of the extreme pressure additive ensures that the gear and bearing friction surfaces are clean and can form an effective protective film on the metal-to-metal contact surface.It protects gears and bearings even under severe load conditions, improving power and transmission efficiency.
◆Excellent oxidation stability: Contains very effective antioxidants, which effectively slows down the oxidation process and prolongs the service life.
◆ It has high thermal stability and is not easy to thicken, thus reducing power loss.
◆Excellent rust and water separation: Protect the metal surface from corrosion and corrosion, so that the metal parts are additionally protected, keeping the gear box and the turbine box clean.
◆Good anti-foaming property: perfect oil film strength, better guarantee the normal operation of gears and bearings.
◆ It does not contain toxic substances such as lead, which better meets the requirements of environmental protection.
Technical Parameters
| Test items | BX-300/E(120/A)150 | BX-300/E(120/A)220 | BX-300/E(120/A)320 | BX-300/E(120/A)460 | Test Methods | |
| colour | ： | Transparent liquid | Transparent liquid | Transparent liquid | Transparent liquid | IP196 |
| Dip index | ： | 102 | 100 | 99 | 98 | |
| Dynamic viscosity @100℃ | ： | 14.4 CST | 18.4 CST | 23.4 CST | 30.0 CST | ASTM D455 |
| Dynamic viscosity @40℃ | 9 139.6CST | 9 203.8CST | 9 293.6CST | 9 431.3CST | ASTM D455 | |
| Working temperature℃ | ： | -25℃ to +150℃ | -25℃ to +150℃ | -25℃ to +150℃ | -25℃ to +150℃ | |
| Pour point ℃ | ： | -18℃ | -18℃ | -18℃ | -18℃ | ASTM D97 |
| Flash point °C | ： | 238℃ | 241℃ | 248℃ | 249℃ | ASTM D92 |
| Fzg load level | ： | 12 | 12 | 12 | 12 | |
| AGMA 250.04 | ： | 4EP | 5EP | 6EP | 7EP | |
| Nsf registration number | ： | 153264/H1 | 153264/H1 | 153264/H1 | 153264/H1 |
Precautions:
◆ It should be stored indoors. If it is stored in the open air, the barrel should be placed horizontally to avoid the infiltration of water and the annihilation of the mark on the barrel.
◆ This product is forbidden to be mixed with water and foreign matter pollution, otherwise it will lead to deterioration and failure.
◆ Do not mix with other oils to prevent performance deterioration.
◆ According to the oil regulations for equipment, choose oils with appropriate viscosity.
Scope of application: It is suitable for the lubrication of gears working under various heavy or shock loads and turbine actuators with different loads. It can also be used in circulation systems with limited lubrication, such as sliding and rolling bearings subjected to heavy loads, and also for splash lubrication. And oil mist lubrication system.
Standard models: BX-300/E (120/A) 150, BX-300/E (120/A) 220, BX-300/E (120/A) 320, BX-300/E (120/A) 460
Specifications: 20LIT/ barrel (plastic barrel)
Storage: indoor, normal temperature, avoid direct sunlight
The above information is for reference only. The actual performance and application are subject to the customer test results. Please pay attention to the test. Please use it after the test.
