Product Features
| Test items | BX-804 | BX-804/A | BX-804/D | Test Methods |
| Colour | Transparent grease | Transparent grease | Transparent grease | IP196 |
| Base oil | Semi-synthetic oil | Semi-synthetic oil | Semi-synthetic oil | |
| Penetration | 220-250 | 175-205 | 220-250 | GB/T 269 |
| Consistency value (NLGI) | 3 | 4 | 3 | |
| Working temperature ℃ | -15℃, to +200℃ | -15℃ to +180℃ | -15℃ to +150℃ | |
| Drop point ℃ | no | no | 250℃ | GB/T 3498 |
| Flash point℃ | 300℃ | 300℃ | 300℃ | |
| Copper corrosion (100 ℃/ 24Hrs) | qualified | qualified | qualified | GB/T 7326 |
| Four ball test (40kg/1 Hrs /1200rpm/75℃) | 250KG | 250KG | 250KG | GB/T 0202 |
| Viscosity level | Medium to high viscosity | Medium viscosity | Medium to high viscosity |
Temperature And Torque Value Changes
| BX-804/A | Ambient temperature | 50℃ | 35℃ | 25℃ | 15℃ | 5℃ | 0℃ | -10℃ | -20℃ |
| Torque value | About 100 | About 108 | About 120 | About 128 | About 135 | About 140 | About 150 | About 160 | |
| BX-804 BX-804/D | Ambient temperature | 50℃ | 35℃ | 25℃ | 15℃ | 5℃ | 0℃ | -10℃ | -20℃ |
| Torque value | About 130 | About 135 | About 140 | About 145 | About 150 | About 160 | About 170 | About 175 |
Scope 0f Application
Applicable to all types of large, medium and small gear transmission structures.
Good water resistance, suitable for all kinds of water supplies.
The damping force is moderate and the high and low temperature performance is stable.
It is necessary to dampen various types of rotation or up and down sliding parts of slow vibration resistance.
Standard models: BX-804, BX-804/A, BX-804/D
Specification: 15KG/ barrel (plastic barrel)
Storage: indoor, normal temperature, avoid direct sunlight
The above information is for reference only. The actual performance and application are subject to the customer test results. Please pay attention to the test. Please use it after the test.
